95D-R3 datasheet(2/2 Pages) YUANDEAN

2 / 2 page

General Specifications

Parameters

Conditions

Min

Typ

Max

Units

Isolation Voltage

1500

Vdc

Isolation Resistance

500Vdc

1000

MΩ

Switching Frequency

300

KHz

Operating

Temperature

With derating

-40

℃

Storage Temperature

-55

125

℃

Humidity

Non Condensing

Cooling

Natural Convection (20LFM)

Case material

Nickel coated copper with no-conductive base

MTBF

MIL-HDBK-217F

@25℃

659000

Hours

Weight

32.6

Dimensions

50.8x25.4x10.6

Recommended Test Circuit

95D-R3 SERIES

YUAN DEAN SCIENTIFIC CO.,LTD

Rev:0 2018/10/31

Part Number

95D-

A: Series

B: Input Voltage

C: Single Output

D: Output Voltage

E: Regulated(R)

F: Package

G: RoHs Version

Output Specifications

Parameters

Conditions

Min

Typ

Max

Units

Voltage Tolerance

Full load@Vin(nom.)

±2

Short Circuit

Protection

Hiccup,

automatic recovery

Line Regulation

±0.5

Load Regulation

Single

Dual(Balance Load)

±0.5

±1

Cross Regulation

Dual (25% to 100% load)

±5

Ripple & Noise

Output:3-15V TYPES

BW=DC To 20MHz

100

mVp-p

Output > 15V TYPES

BW=DC To 20MHz

1% of Vout

mVp-p

Transient response

setting time

25% load step change

300

Dimensions

PIN Assignment

Single

+Vin

-Vin

+Vout

Trim

-Vout

Remote

On/Off

Dual

+Vin

-Vin

+Vout

Com

-Vout

Remote

On/Off
