FP1008R5-R220-R Datasheet(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP1008R5-R220-R Datasheet(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 7 page  Technical Data 10520 Effective April 2017 FP1008R5 and FP1008R6 High frequency, high current power inductors Product features • High current carrying capacity • Low core loss • Magnetically shielded • Tight tolerance DCR for sensing circuits • Inductance Range from 100 nH to 300 nH • Current range from 36 A to 103 A • 10.8 mm x 8.0 mm footprint surface mount package in an 8.0 mm height • Moisture Sensitivity Level: 1 • Ferrite core material Applications • Multi-phase and Vcore regulators • Voltage Regulator Modules (VRMs) and high power density VRMs • Server and desktop • Central processing unit (CPU) • Graphics processing unit (GPU) • Application specific integrated circuit (ASIC) • Data networking and storage systems • Graphics cards and battery power systems • Point-of-Loadmodules (POL) • DCR sensing circuits Environmental data • Storage temperature range (Component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant • Halogen free, lead free, RoHS compliant Pb HALOGEN HF FREE |
