Product data sheet

Connections and Schema

TM5SDO2R

Electronic Module 2DO 30 Vdc/230 Vac 5 A Relay C/O

Wiring Diagram

(1)

Internal electronics

(2)

24 Vdc I/O power segment integrated into the bus bases

(3)

External power supply 100...240 Vac

(4)

Inductive load protection

(5)

2-wire load

(6)

External power supply 24 Vdc

(7)

External fuse type T slow-blow 5 A - 250 V
