JVR Datasheet(PDF) 11 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
JVR Datasheet(HTML) 11 Page - List of Unclassifed Manufacturers |
|
|
11 / 20 page  Metal Oxide Varistor JVR Series 10 Ø 10mm Rating and Characteristics Part No. Varistor Voltage at 1mA Maximum Allowable Voltage Maximum Clamping Voltage Withstanding Surge Current (8/20us) Nominal Discharge Current (8/20us) Rated Wattage Energy (10/1000us) Certification DC ( V ) Tolerance AC rms ( V ) DC ( V ) V@ ic ( V ) ic ( A ) 1 Time ( A ) In ( KA ) (W) (J) JVR 10S 180M 18 ±20% 11 14 36 5 1000 0.5 0.05 2.6 ☆ ○ □ JVR 10S 220L 22 ±15% 14 18 43 5 1000 0.5 0.05 3.2 ☆ ○ □ JVR 10S 270K 27 ±10% 17 22 53 5 1000 0.5 0.05 3.9 ☆ ○ □ JVR 10S 330K 33 ±10% 20 26 65 5 1000 0.5 0.05 4.8 ☆ ○ □ JVR 10S 390K 39 ±10% 25 31 77 5 1000 0.5 0.05 5.6 ☆ ○ □ JVR 10S 470K 47 ±10% 30 38 93 5 1000 0.5 0.05 6.8 ☆ ○ □ JVR 10S 560K 56 ±10% 35 45 110 5 1000 0.5 0.05 8.1 ☆ ○ □ JVR 10S 680K 68 ±10% 40 56 135 5 1000 0.5 0.05 9.8 ☆ ○ □ JVR 10S 820K 82 ±10% 50 65 135 25 3500 1.5 0.4 14 ☆ ○ □ JVR 10S 101K 100 ±10% 60 85 165 25 3500 1.5 0.4 18 ☆ ○ □ JVR 10S 121K 120 ±10% 75 100 200 25 3500 1.5 0.4 22 ☆ ○ □ JVR 10S 151K 150 ±10% 95 125 250 25 3500 1.5 0.4 25 ☆ ○ □ JVR 10S 181K 180 ±10% 115 150 300 25 3500 3 0.4 32 ☆ ● □ JVR 10S 201K 200 ±10% 130 170 340 25 3500 3 0.4 35 ☆ ● ■ JVR 10S 221K 220 ±10% 140 180 360 25 3500 3 0.4 39 ☆ ● ■ JVR 10S 241K 240 ±10% 150 200 395 25 3500 3 0.4 42 ☆ ● ■ JVR 10S 271K 270 ±10% 175 225 455 25 3500 3 0.4 49 ☆ ● ■ JVR 10S 301K 300 ±10% 195 250 505 25 3500 3 0.4 52 ☆ ● ■ JVR 10S 331K 330 ±10% 210 275 550 25 3500 3 0.4 58 ☆ ● ■ JVR 10S 361K 360 ±10% 230 300 595 25 3500 3 0.4 65 ☆ ● ■ JVR 10S 391K 390 ±10% 250 320 650 25 3500 3 0.4 70 ☆ ● ■ JVR 10S 431K 430 ±10% 275 350 710 25 3500 3 0.4 80 ☆ ● ■ JVR 10S 471K 470 ±10% 300 385 775 25 3500 3 0.4 85 ☆ ● ■ JVR 10S 511K 510 ±10% 320 418 842 25 3500 3 0.4 92 ☆ ● ■ JVR 10S 561K 560 ±10% 350 460 920 25 3500 3 0.4 102 ☆ ● ■ JVR 10S 621K 620 ±10% 385 505 1025 25 3500 3 0.4 107 ☆ ● ■ JVR 10S 681K 680 ±10% 420 560 1120 25 3500 3 0.4 112 ☆ ● ■ JVR 10S 751K 750 ±10% 460 615 1240 25 3500 3 0.4 115 ☆ ● ■ JVR 10S 781K 780 ±10% 485 640 1290 25 3500 3 0.4 116 ☆ ● ■ JVR 10S 821K 820 ±10% 510 670 1355 25 3500 3 0.4 118 ☆ ● ■ JVR 10S 911K 910 ±10% 550 745 1500 25 3500 3 0.4 127 ☆ ● ■ JVR 10S 102K 1000 ±10% 625 825 1650 25 3500 3 0.4 140 ☆ ● ■ JVR 10S 112K 1100 ±10% 680 895 1815 25 3500 3 0.4 155 ☆ ● ■ JVR 10S 122K 1200 ±10% 720 975 1980 25 3500 1.5 0.4 168 ☆ ● ■ JVR 10S 142K 1400 ±10% 825 1135 2310 25 3500 1.5 0.4 195 ☆ ● ■ JVR 10S 162K 1600 ±10% 920 1300 2640 25 3500 1.5 0.4 222 ☆ ● ■ JVR 10S 182K 1800 ±10% 1000 1465 2970 25 3500 1.5 0.4 247 ☆ ● ■ |
|
|
