831724 Datasheet
Parameter Measurement Information, continued
Input Skew
Differential Measurement Points for Duty Cycle/Period
Single-ended Measurement Points for Delta Cross Point
Differential Measurement Points for Rise/Fall Edge Rate
Differential Measurement Points for Ringback
Single-ended Measurement Points for Absolute Cross
Point/Swing
t
PD2
t
PD1
tsk(i) = |tPD1 - tPD2|
tsk(i)
nCLKy
CLKy
nQ[A:D]
Q[A:D]
nCLKx
CLKx
