E L E C T R O N I C S I N C .

Surface Mount Power Inductor

TEL: (818) 892-0761

FAX: (818) 894-5791

http://www.pca.com

PCA ELECTRONICS, INC.

16799 SCHOENBORN ST.

NORTH HILLS, CA 91343

• Low loss material ensures operation in high frequency

switching converters, such as Buck, Boost or as output

averaging filter inductor

• Also suitable for use in high quality filter applications

• 250 KHz & 500 KHz Switching Frequency

Schematic

EPI BSPH68 Series

Product performance is limited to specified parameters. Data is subject to change without prior notice.

Package

Electrical Parameters @ 25° C

Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25

Temp. Rise

(C° Typ.)

Connection

Series

Parallel

Series

Parallel

Series

Parallel

Part

Number

EPI1L1383BSPH68

EPI2L3273BSPH68

EPI3L2243BSPH68

DCR

(

Ω Typ.)

.004

.001

.0090

.0023

.012

.003

Vt 1

(V-µsec.)

@ 250 Khz

8.8

4.4

12.4

6.2

15.2

7.6

Idc

(A)

13.5

Inductance

(µH ± 15%)

@ Idc

4.47

1.1

9.12

2.3

12.9

3.2

@ Vt1

@ Vt2

Inductance

(µH ± 15%)

@ Odc

7.74

1.94

15.8

3.95

28.4

7.1

Vt 2

(V-µsec.)

@ 500 Khz

5.8

2.9

8.2

4.1

9.4

4.7

Note : 1) Core loss at ref. Vt1 & Vt2 = 124 mW.

1.220 Max.

(30.99)

1.00

Max.

(25.40)

.500

Max.

(12.70)

1.097

(27.86)

.600

(15.24)

.400

(10.16)

.155

(3.94)

1.100

(27.94)

Suggested

Pad

Layout

PCA

EPIXXXXXXBSPH68

D.C.

.320

(8.13)

CSIXXXXXXBSPH68

Rev. -

7/18/02
