Radial Lead Power Inductor

TEL: (818) 892-0761

FAX: (818) 894-5791

http://www.pca.com

PCA ELECTRONICS, INC.

16799 SCHOENBORN ST.

NORTH HILLS, CA 91343

• Virtually no limit on V µSec. as long as max. RMS Current Limit

and Temperature Rise Limit are not exceeded

• Low loss material ensures operation in high frequency

switching converters, such as Buck, Boost or as output

averaging filter inductor

• Also suitable for use in high quality filter applications

• Low cost Robust construction to withstand most SMT processes

EPI RL30 Series

Product performance is limited to specified parameters. Data is subject to change without prior notice.

Primary Specification

Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25

CSIXXXXXXRL30a

Rev. 3

12/12/02

1.0 ± 20%

1.5 ± 20%

2.2 ± 20%

3.3 ± 20%

4.7 ± 20%

6.8 ± 20%

10 ± 20%

12 ± 20%

15 ± 10%

18 ± 10%

22 ± 10%

27 ± 10%

33 ± 10%

39 ± 10%

47 ± 10%

56 ± 10%

68 ± 10%

82 ± 10%

100 ± 10%

120 ± 10%

150 ± 10%

180 ± 10%

Inductance

(µH)

@ 0 Adc

DCR

(

Ω Max.)

0.013

0.016

0.021

0.025

0.030

0.035

0.05

0.06

0.07

0.08

0.09

0.11

0.13

0.14

0.15

0.18

0.20

0.24

0.28

0.36

0.42

0.57

I dc

(mA Max.)

10000

8500

6500

5500

4300

3700

2900

2500

2200

1900

1800

1700

1500

1300

1200

1100

1000

890

810

720

660

Test Frequency

(MHz Typ.)

7.96

2.52

1.0

Part Number

(add “A” for Heat Shrink Tube)

EPI1L0103RL30

EPI1L5852RL30

EPI2L2652RL30

EPI3L3552RL30

EPI4L7432RL30

EPI6L8372RL30

EPI100292RL30

EPI120252RL30

EPI150222RL30

EPI180192RL30

EPI220182RL30

EPI270172RL30

EPI330152RL30

EPI390132RL30

EPI470132RL30

EPI560122RL30

EPI680112RL30

EPI820102RL30

EPI101891RL30

EPI121811RL30

EPI151721RL30

EPI181661RL30

Package RL30A

(With Heat Shrink Tube)

Note :

1. Temperature Rise : 40°C Max. @ Idc

2. Inductance Drop : 10% Max. @ Idc

3. Leads are pre-tinned

.295

(7.50)

.307 Typ.

(7.80)

.0275

(.700)

.197

(5.00)

.197 ± .012

(5.00 ± .300)

.295

(7.50)

.307 ± .020

(7.80 ± .500)

.0275

(.700)

.197

(5.00)

.197 ± .012

(5.00 ± .300)

Package RL30

(Without Heat Shrink Tube)
