 2 / 3 page
background image
2/3
DATA SHEET
Assemblies
Simplex_SC-SC_APC_2.0mm_yellow_SM/A2
PC01_SCAS_SCAS_A220E_XX.X_SS
Side B / Right
Polishing
APC
Insertion loss 97%
≤ 0.45 dB
Insertion loss typical
≤ 0.2 dB
Return loss
≥ 65 dB
Fiber Optic Cable
Cable Description
Simplex cable
Fiber quantity
1
Fiber type
E9/125A2
CPR class
Dca-s1a,d0,a1
Strain relief
aramide yarn
Outer tube diameter
1 x 0.9 mm
Outer jacket diameter
2mm
Outer jacket material
PE flame retardant
Tensile strength during installation
400 N
Tensile strength in service
200 N
Min. bending radius during installation
50 mm
Min. bending radius in service
50 mm
Crush resistance during installation
3000 N/dm
Crush resistance in service
1000 N/dm
1000 N/dm
Fire propagation standard
IEC 60332-1-2
IEC 60332-3-25
Technical drawing
Ordering Information Table
Item number
Item description
Length in m
85031229
PC01_SCAS_SCAS_A220E_01.0_SS
1
85031230
PC01_SCAS_SCAS_A220E_02.0_SS
2
85031231
PC01_SCAS_SCAS_A220E_03.0_SS
3
85031232
PC01_SCAS_SCAS_A220E_05.0_SS
5
85031233
PC01_SCAS_SCAS_A220E_06.0_SS
6
85031234
PC01_SCAS_SCAS_A220E_07.0_SS
7
hubersuhner.com
