DATA SHEET

Assemblies

Simplex_SC-SC_APC_2.0mm_yellow_SM/A2

PC01_SCAS_SCAS_A220E_XX.X_SS

Properties

• One-piece design

for easy and quick

termination

• Push-pull connector

General data

Assembly family

Simplex patch cord - SC to SC

Application Area

Indoor

Fiber quantity

1 pcs

Flammability rating

UL 94 V-0

Operation temperature

-25 °C ... 70°C

Side A / Le

Type

Fiber Optic Connector

Connector family

SC

Gender

Plug

Housing colour FO Connector

Green

Boot colour

Green

Mating cycles with repeated cleaning

1000

Mechanical Inte ace Standard

IEC 61754-4, TIA 604-3 (SC)

Pe ormance class H+S

S

Polishing

APC

Insertion loss 97%

≤ 0.45 dB

Insertion loss typical

≤ 0.2 dB

Return loss

≥ 65 dB

Side B / Right

Type

Fiber Optic Connector

Connector family

SC

Gender

Plug

Housing colour FO Connector

Green

Boot colour

Green

Mating cycles with repeated cleaning

1000

Mechanical Inte ace Standard

IEC 61754-4, TIA 604-3 (SC)

Pe ormance class H+S

S

hubersuhner.com
