Table 1.17

Pin functions (2 of 7)

Classification

Pin name

I/O

Description

System control

RES#

Input

Inputs the reset signal. This MPU enters the reset state

when this signal goes low.

BSCANP

Input

Inputs the boundary scan enable signal. Boundary

scan is enabled when this pin goes high. When

boundary scan is not used, this pin should be driven

low.

RSTOUT#

Output

Outputs the reset signal externally

Debugging interface

TRST#

Input

Test reset pin for the on-chip emulator

TMS

I/O

Test mode select pin for the on-chip emulator

Functions as the SWDIO pin in serial wire debug

(SWD) mode

TDI

Input

Test data input pin for the on-chip emulator

TDO

Output

Test data output pin for the on-chip emulator

TCK

Input

Test clock pin for the on-chip emulator

Functions as the SWCLK pin in serial wire debug

(SWD) mode

TRACECLK

Output

Outputs the clock for synchronization with trace data

TRACECTL

Output

Outputs the enable signal for trace control

TRACEDATA0 to TRACEDATA7

Output

Output trace data

RZ/T2M Datasheet

1. Overview

R01DS0383EJ0130 Rev.1.30

Mar 13, 2026

Page 14 of 128
