5 / 14 page

sensing.honeywell.com

MICRO SWITCH™ Miniature Sealed Basic Switches

Table 1. Specifications

Characteristic

SE Series

XE Series

Description

environmentally sealed switch

environmentally sealed miniature switch

Housing material

Anodized aluminum

Mechanical endurance

please contact info.sc@honeywell.com for details

25,000

Electrical endurance

please contact info.sc@honeywell.com for details

25,000

Circuitry

SPST (NC), SPST (NO), SPDT

Electrical termination

epoxy sealed leadwire, (0,52 mm² [20 awg]) or

epoxy sealed solder pins

epoxy sealed leadwire, (0,52 mm² [20 awg]) or

epoxy sealed solder pins

Electrical rating

5 A @ 30 Vdc; 5 A @ 250 Vac, 60 Hz

7 A @ 28 Vdc; 7 A @ 250 Vac, 60 Hz

Sealing

Symbol 3 “watertight” per MIL-PRF-8805

Temperature range

-53 °C to 105 °C [-65 °F to 221 °F] (standard)

-26 °C to 85 °C [-15 °F to 185 °F] (5SE Series)

-53 °C to 105 °C [-65°F to 221 °F] (standard)

-26 °C to 85 °C [-15 °F to 185 °F] (5XE Series)

Temperature range (optional)

please contact info.sc@honeywell.com for details

-53 °C to 149 °C [-65°F to 300 °F] (14XE Series)

Vibration

Grade 2 (15 G) per MIL-PRF-8805

Approvals

UL, CSA

UL, MIL-PRF-8805

Actuators

Top pin plunger, optional auxiliary actuators available

Table 2. Electrical Ratings

Rating code

SE/XE Series

Sea level @ 28 Vdc; 5 A res. and 3 A ind.

50,000 feet @ 28 Vdc; 5 A res. and 2.5 A ind.

General purpose; 5 A res. and 5 A ind. at 125 or 250 Vac, 60 Hz

UL and CSA rating; 5 A at 125 or 250 Vac, 60 Hz

Sea level @ 28 Vdc; 7 A res. and 4 A ind.

50,000 feet @ 28 Vdc; 7 A res. and 2.5 A ind.

General purpose; 7 A res. and 4 A ind. at 115 Vac, 400 Hz

UL rating; 7 A at 125 or 250 Vac, 60 Hz

Sea level @ 28 Vdc; 7 A res. and 4 A ind.

50,000 feet @ 28 Vdc; 7 A res and 2.5 A ind.

Logic level @ 28 Vdc; 1 amp res. and 0.50 A ind.
