76543210

NO-LOCK

MMAC

SMAC

SMI

RPL

Reserved

Table 2 - 1

CCR1 Register

ST486DX - SMM IMPLEMENTATION

The portions of the Configuration Control Registers (CCR1, CCR2, and CCR3) which apply to

SMM and power management are described in the following pages.

SMI

Enable SMM Pins

SMI = 0:

SMI# input pin is ignored and SMADS# output pin floats. Execution of

SGS Thomson specific SMM instructions will generate an invalid opcode exception.

SMI = 1:

SMI# input/output pin and SMADS# output pin are enabled. SMI must be set

to 1 before any attempted access to SMM memory is made.

SMAC

System Management Memory Access

SMAC = 0:

All memory accesses in normal mode go to system memory with ADS# output

active. In normal mode, execution of SGS Thomson specific SMM instructions

generate an invalid opcode exception.

SMAC = 1:

Memory accesses while in normal mode that fall within the specified SMM

address region generate an SMADS# output and access SMM memory. SMI#

input is ignored.

MMAC

Main Memory Access

MMAC = 0:

All Memory accesses while in SMM mode go to SMM memory with SMADS#

output active.

MMAC = 1:

Data accesses while in SMM mode that fall within the specified SMM address

region will generate an ADS# output and access main memory. Code fetches

are not effected by the MMAC bit. Code fetches from the SMM address region

always generate an SMADS# output and access SMM memory. If both the

SMAC and MMAC bits are set to 1, the MMAC bit has precedence.
