RGF3AB – RGF3MAB

3.0A Sintered Glass Passivated Fast Recovery Rectifier

Fig.2- Maximum Non-Repetitive Forward Surge Current

Number of Cycles at 60Hz

Symbol

Description

RGF

3AB

RGF

3BB

RGF

3DB

RGF

3GB

RGF

3JB

RGF

3JAB

RGF

3KB

RGF

3KAB

RGF

3MB

RGF

3MAB

Unit

Conditions

Trr

Max. Reverse

Recovery Time

150

250

150

500

300

500

300

nS

55

Typical Thermal

Resistance

15

°C / W

Note 2

Typical Junction

Capacitance

60

pF

f=1MHz

Operating Junction

and Storage

Temperature Range

-65 to +175

° C

2. Thermal resistance from junction to ambient and from junction to lead P.C.B mounted on

0.2 × 0.2” (5.0 × 5.0mm) copper pad areas.

Typical Characteristics Curves

Fig.1- Forward Current Derating Curve

Lead Temperature (°C)
