ThunderLAN

™ TNETE100PM

PCI ETHERNET

™ CONTROLLER WITH POWER MANAGEMENT

SINGLE-CHIP 10 BASE-T WITH MII FOR 100 BASE-T/100VG-AnyLAN

SPWS026 – OCTOBER 1996

18

POST OFFICE BOX 1443

switching characteristics for 5-V and 3.3-V PCI (see Note 15 and Figure 4)

PARAMETER

MIN

MAX

UNIT

tVAL

Delay time, PCLK to bused signals valid (see Notes 16 and 17)

2

11

ns

tVAL(PTP) Delay time, PCLK to bused signals valid point-to-point (see Notes 16 and 17)

2

12

ns

ton

Float to active delay

2

ns

toff

Active to float delay

28

ns

NOTES: 15. Some of the timing symbols in this table are not currently listed with EIA or JEDEC standards for semiconductor symbology but are

consistent with the PCI Local-Bus Specification, Revision 2.0.

16. Minimum times are measured with a 0-pF equivalent load; maximum times are measured with a 50-pF equivalent load. Actual test

capacitance may vary, but results should be correlated to these specifications.

17. PREQ and PGNT are point-to-point signals and have different output-valid delay and input-setup times than do bused signals. PGNT

has a setup time of 10 ns; PREQ has a setup time of 12 ns. All other signals are bused.

timing requirements for 5-V and 3.3-V PCI (see Note 15 and Figure 4)

MIN

MAX

UNIT

tsu

Setup time, bused signals valid to PCLK (see Note 17)

7

ns

tsu(PTP)

Setup time to PCLK—point-to-point (see Note 17)

10, 12

ns

th

Input hold time from PCLK

0

ns

t

Cycle time PCLK (see Note 18)

100 Mbps

30

50

ns

tc

Cycle time, PCLK (see Note 18)

10 Mbps

30

500

ns

tw(H)

Pulse duration, PCLK high

11

ns

tw(L)

Pulse duration, PCLK low

11

ns

tslew

Slew rate, PCLK (see Note 19)

1

4

V/ns

NOTES: 15. Some of the timing symbols in this table are not currently listed with EIA or JEDEC standards for semiconductor symbology but are

consistent with the PCI Local-Bus Specification, Revision 2.0.

17. PREQ and PGNT are point-to-point signals and have different output-valid delay and input-setup times than do bused signals. PGNT

has a setup time of 10 ns; PREQ has a setup time of 12 ns. All other signals are bused.

18. As a requirement for frame transmission /reception, the minimum PCLK frequency varies with network speed. The clock may be

stopped only in a low state.

19. Rise and fall times are specified in terms of the edge rate measured in V/ns. This slew rate must be met across the minimum

peak-to-peak portion of the clock waveform.
