ThunderLAN

™ TNETE110PM

PCI ETHERNET

™ CONTROLLER

SINGLE-CHIP 10 BASE-T

SPWS029 – SEPTEMBER 1996

1

POST OFFICE BOX 1443

Peripheral Component Interconnect (PCI)

Local Bus

– Compliant With PCI Local-Bus

Specification (Revision 2.1)

– 33-MHz Operation

– 3-V or 5-V I/O Operation

– Adaptive Performance Optimization

™

(APO) for Highest Available PCI

Bandwidth

– High-Performance Bus Master

Architecture With Byte-Aligning Direct

Memory Access (DMA) Controller for

Low Host CPU and Bus Utilization

– Plug-and-Play Compatible

– Time Division Multiplexed SRAM

– 2-Gbps Internal Bandwidth

ThunderLAN Components

– Independent Transmit and Receive

Channels

– Two Transmit Channels for Demand

Priority

Register

Management-Information Base (MIB)

Attachment Unit Interface (AUI) Physical

Layer Interface

– Single-Chip IEEE 802.3 and Blue Book

Ethernet-Compliant Solution

– DSP-Based Digital Phase-Locked Loop

– Smart Squelch Allows for Transparent

Link Testing

– Transmission Waveshaping

– Autopolarity (Reverse Polarity

Correction)

– External/Internal Loopback Including

Twisted Pair and AUI

– 10 Base-2 Supported Via AUI Interface

– PCI Specification Compatible for Low

Power/Sleep Mode

– Advanced Configuration and Power

Interface (ACPI)

– Green PC Compatible

Design and Autoconfiguration

Compatible

(JTAG)

Flat Packages (PCM and PGE Suffix)

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

ADVANCE INFORMATION concerns new products in the sampling or

preproduction phase of development. Characteristic data and other

specifications are subject to change without notice.

Copyright

© 1996, Texas Instruments Incorporated

† The PCI Local-Bus Specification, Revision 2.1 should be used as a reference with this document.

‡ IEEE Standard 1149.1–1990, IEEE Standard Test-Access Port and Boundary-Scan Architecture

ThunderLAN and Adaptive Performance Optimization are trademarks of Texas Instruments Incorporated.

Ethernet is a trademark of Xerox Corporation.

Microsoft is a trademark of Microsoft Corporation.

Magic Packet is a trademark of Advanced Micro Devices Corporation.
