20V-40V 2.0A
SSL22 THRU SSL24
Surface Mount Schottk
1 of 2
Web Site: www.taychipst.com
FEATURES
E-mail: sales@taychipst.com
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
MECHANICAL DATA
Barrier Rectifier
•
Low profile surface mount package
•
Built-in strain relief
•
High switching speed, low VF
•
Low voltage drop, high efficiency
•
For use in low voltage high frequency inverters,
Free willing, and polarity protection applications
•
Guarding for over voltage protection
•
Case: Transfer molded plastic
•
Epoxy :UL 94V-0 rate flame retardant
•
Lead: Solder plated, solderable per MIL-STD-750
method 2026
•
Polarity: Color band denotes cathode end
•
Weight: 0.003 ounce, 0.093 gram
Rating at 25 ℃ ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Symbol
Unit
VRRM
V
VRMS
V
VDC
V
IF(AV)
A
TJ
OC
TSTG
OC
Typical Thermal Resistance (Note 2)
RθjL
RθjA
25
70
OC/W
Maximum Instantaneous Forward Voltage (Note 1)
@ 2 A
VF
0.41
V
SL23
SL24
- 55 to + 125
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method)
IFSM
Type Number
Maximum Average Forward Rectified Current
14
Maximum RMS Voltage
Maximum DC Blocking Voltage
40
IR
Note 2: Mount on Cu-Pad Size 10mm × 10mm on P.C.B.
Marking Code
Note 1: Pulse Test with PW=300u sec, 1% Duty Cycle
Operating Temperature Range
Storage Temperature Range
Maximum DC Reverse Current
TA=25 ℃
at Rated DC Blocking Voltage
TA=100 ℃
Maximum Repetitive Peak Reverse Voltage
30
28
40
2
21
0.4
- 55 to + 150
SL22
20
30
SSL22
SSL23
50
60
80
SSL24
mA
20
A
