Description

This evaluation board can be used to evaluate the SPEAr320S microprocessor with a

variety of devices and especially its Media Independent Interface (MII) Automation mode.

The EVALSP320SPLC evaluation kit includes a single application board identified as "MII

mode".

The SPEAr320S microprocessor is mounted on a separate CPU board, which is not

included with the EVALSP320SPLC kit. It must be ordered separately with order code

EVALSP320SCPU.

The EVALSP320SCPU board must be plugged on the MII mode application board.

The MII mode application board is equipped with two Ethernet, three RS-232, one RS-485,

two CAN, SPI, I2C communication interfaces and MicroSD card socket with SDIO interface.

There are also two general-purpose push-buttons, four LEDs, a temperature sensor and a

potentiometer available for the user interface.

The application board also includes digital input/output serial/parallel connectors with a

pinout compatible to many existing evaluation boards from ST.

The application board can be powered using a standard DC power supply (7 V to 30 V DC)

or directly using a 24 V DC industrial mains supply.
