100 / 143 page  Command codes M24LR16E-R 100/143 Doc ID 018932 Rev 8 Response parameters: ● Information flags set to 0Fh. DSFID, AFI, Memory Size and IC reference fields are present. ● UID code on 64 bits ● DSFID value ● AFI value ● Memory size. The M24LR16E-R provides 512 blocks (01FFh) of 4 byte (03h) ● IC reference: the 8 bits are significant. Response parameter: ● Error code as Error_flag is set: – 03h: Option not supported . When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that starts the Get System Info command to the end of the M24LR16E-R response. When configured in the RF write in progress mode, the RF WIP/BUSY pin remains in high-Z state. Table 72. Get System Info response format when Error_flag is set Response SOF Response_flags Error code CRC16 Response EOF 01h 8 bits 16 bits Figure 65. Get System Info frame exchange between VCD and M24LR16E-R VCD SOF Get System Info request EOF M24LR16E-R <-t1-> SOF Get System Info response EOF |
|
