Command codes
M24LR64E-R
100/140
Doc ID 022712 Rev 3
Response parameters:
●
Sector security status (see Table 75)
Response parameter:
●
Error code as Error_flag is set:
–
03h: the option is not supported
–
10h: the specified block is not available
When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that
starts the Get Multiple Block Security Status command to the end of the M24LR64E-R
response.
When configured in the RF write in progress mode, the RF WIP/BUSY pin remains in high-Z
state.
Table 74.
Get Multiple Block Security Status response format when Error_flag is
NOT set
Response
SOF
Response_
flags
Sector security
status
CRC16
Response
EOF
8 bits
8 bits(1)
1.
Repeated as needed.
16 bits
Table 75.
Sector security status
b7
b6
b5
b4
b3
b2
b1
b0
Reserved for future use
All at 0
Password control
bits
Read / Write
protection bits
0: Current sector not locked
1: Current sector locked
Table 76.
Get Multiple Block Security Status response format when Error_flag is
set
Response
SOF
Response_
flags
Error code
CRC16
Response
EOF
8 bits
8 bits
16 bits
Figure 66.
Get Multiple Block Security Status frame exchange between VCD and
M24LR64E-R
VCD
SOF
Get Multiple Block
Security Status
EOF
M24LR64E-R
<-t1-> SOF
Get Multiple Block
Security Status
EOF
