background image
Command codes
M24LR64E-R
110/140
Doc ID 022712 Rev 3
Response parameters:
●
Sector security status if Option_flag is set (see Table 97)
●
N block of data
Response parameter:
●
Error code as Error_flag is set:
–
03h: the option is not supported
–
10h: block address not available
–
15h: block read-protected
When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that
starts the Fast Read Multiple Block command to the end of the M24LR64E-R response.
When configured in the RF write in progress mode, the RF WIP/BUSY pin remains in high-Z
state.
Table 96.
Fast Read Multiple Block response format when Error_flag is NOT set
Response
SOF
Response_
flags
Sector
security
status(1)
1.
Gray color means that the field is optional.
Data
CRC16
Response
EOF
8 bits
8 bits(2)
2.
Repeated as needed.
32 bits(2)
16 bits
Table 97.
Sector security status if Option_flag is set
b7
b6
b5
b4
b3
b2
b1
b0
Reserved for future use
All at 0
Password
control bits
Read / Write
protection bits
0: Current sector not locked
1: Current sector locked
Table 98.
Fast Read Multiple Block response format when Error_flag is set
Response SOF
Response_flags
Error code
CRC16
Response EOF
8 bits
8 bits
16 bits
Figure 72.
Fast Read Multiple Block frame exchange between VCD and M24LR64E-R
VCD
SOF
Fast Read
Multiple Block
request
EOF
M24LR64E-R
<-t1-> SOF
Fast Read
Multiple Block
response
EOF
