M95128-W M95128-R M95128-DF
DC and AC parameters
Doc ID 5798 Rev 16
39/49
Table 21.
AC characteristics (M95128-DF, device grade 6)
Test conditions specified in Table 11 and Table 12(1)
Parameter
VCC ≥ 1.7 V
CL ≤100 pF
VCC ≥ 2.5 V
CL ≤30 pF
VCC ≥ 4.5 V
CL ≤30 pF
Unit
Min.
Max. Min.
Max.
Min. Max.
fC
fSCK Clock frequency
5
10
20
MHz
tSLCH
tCSS1 S active setup time
60
30
15
ns
tSHCH
tCSS2 S not active setup time
60
30
15
ns
tSHSL
tCS
S deselect time
90
40
20
ns
tCHSH
tCSH S active hold time
60
30
15
ns
tCHSL
S not active hold time
60
30
15
ns
tCH
(2)
tCLH Clock high time
80
40
20
ns
tCL
(3)
tCLL
Clock low time
80
40
20
ns
tCLCH
(3)
tRC
Clock rise time
2
2
2
µs
tCHCL
(4)
tFC
Clock fall time
2
2
2
µs
tDVCH
tDSU Data in setup time
20
10
5
ns
tCHDX
tDH
Data in hold time
20
10
10
ns
tHHCH
Clock low hold time after HOLD not active
60
30
15
ns
tHLCH
Clock low hold time after HOLD active
60
30
15
ns
tCLHL
Clock low setup time before HOLD active
0
0
0
ns
tCLHH
Clock low setup time before HOLD not active
0
0
0
ns
tSHQZ
(4)
tDIS
Output disable time
80
40
20
ns
tCLQV
tV
Clock low to output valid
80
40
20
ns
tCLQX
tHO
Output hold time
0
0
0
ns
tQLQH
(4)
tRO
Output rise time
80
20
10
ns
tQHQL
(4)
tFO
Output fall time
80
20
10
ns
tHHQV
tLZ
HOLD high to output valid
80
40
20
ns
tHLQZ
(4)
tHZ
HOLD low to output High-Z
80
40
20
ns
tW
tWC
Write time
5
5
5
ms
1.
Preliminary data.
2.
tCH + tCL must never be less than the shortest possible clock period, 1 / fC(max).
3.
Characterized only, not tested in production.
