*All dimensions are nominal
Device
Package Type
Package Drawing
Pins
SPQ
Length (mm)
Width (mm)
Height (mm)
TLV2241IDBVR
SOT-23
DBV
5
3000
182.0
182.0
20.0
TLV2241IDBVT
SOT-23
DBV
5
250
182.0
182.0
20.0
TLV2241IDR
SOIC
D
8
2500
340.5
338.1
20.6
TLV2241IDR
SOIC
D
8
2500
367.0
367.0
35.0
TLV2242CDR
SOIC
D
8
2500
340.5
338.1
20.6
TLV2242IDGKR
VSSOP
DGK
8
2500
358.0
335.0
35.0
TLV2242IDR
SOIC
D
8
2500
340.5
338.1
20.6
TLV2244IDR
SOIC
D
14
2500
367.0
367.0
38.0
TLV2244IPWR
TSSOP
PW
14
2000
367.0
367.0
35.0
PACKAGE MATERIALS INFORMATION
www.ti.com
21-Sep-2012
Pack Materials-Page 2
