 4 / 21 page
background image
ADP5300
Data Sheet
Rev. 0 | Page 4 of 21
SPECIFICATIONS
VIN = 3.6 V, VOUT = 2.5 V, TJ = −40°C to +125°C for minimum and maximum specifications, and TA = 25°C for typical specifications,
unless otherwise noted.
Table 1.
Parameter
Symbol
Min
Typ
Max
Unit
Test Conditions/Comments
INPUT SUPPLY VOLTAGE RANGE
VIN
2.15
6.50
V
SHUTDOWN CURRENT
ISHUTDOWN
18
40
nA
VEN = 0 V, −40°C ≤ TJ ≤ +85°C
18
130
nA
VEN = 0 V, −40°C ≤ TJ ≤ +125°C
QUIESCENT CURRENT
Operating Quiescent Current in
Hysteresis Mode
IQ_HYS
180
260
nA
−40°C ≤ TJ ≤ +85°C
180
350
nA
−40°C ≤ TJ ≤ +125°C
570
1400
nA
100% duty cycle operation,
VIN = 3.0 V, VOUT set to 3.3 V
Operating Quiescent Current in
Hysteresis Mode
IQ-HYS2
2.3
3.2
µA
VIN = 3.6 V, VSTOP = 3.6 V
Operating Quiescent Current in PWM
Mode
IQ_PWM
425
630
µA
UNDERVOLTAGE LOCKOUT
UVLO
UVLO Threshold
Rising
VUVLO_RISING
2.06
2.14
V
Falling
VUVLO_FALLING
1.90
2.00
V
OSCILLATOR CIRCUIT
Switching Frequency in PWM Mode
fSW
1.7
2.0
2.3
MHz
Feedback (FB) Threshold of Frequency
Fold
VOSC_FOLD
0.3
V
SYNCHRONIZATION THRESHOLD
SYNC Clock Range
SYNCCLOCK
1.2
2.5
MHz
SYNC High Level Threshold
SYNCHIGH
1.2
V
SYNC Low Level Threshold
SYNCLOW
0.4
V
SYNC Duty Cycle Range
SYNCDUTY
100
1/fSW − 150
ns
SYNC/MODE Leakage Current
ISYNC_LEAKAGE
50
150
nA
VSYNC/MODE = 3.6 V
MODE TRANSITION
Transition Delay from Hysteresis Mode
to PWM Mode
tHYS_TO_PWM
20
Clock cycles
SYNC/MODE goes logic high
from logic low
EN PIN
Input Voltage Threshold
High
VIH
1.2
V
Low
VIL
0.4
V
Input Leakage Current
IEN_LEAKAGE
25
nA
STOP Switching
PWM Switching Stop Delay
tSTOP-RISE-DELAY
10
ns
STOP goes logic high from low
PWM Switching Resume Delay
tSTOP-FALL-DELAY
20
ns
STOP goes logic low from high
FB PIN
Output Options by VID Resistor
VOUT_OPT
0.8
5.0
V
0.8 V to 5.0 V in various factory
options
PWM Mode
Fixed VID Code Voltage Accuracy
VFB_PWM_FIX
−0.6
+0.6
%
TJ = 25°C, output voltage setting
via factory fuse
−1.2
+1.2
%
−40°C ≤ TJ ≤ +125°C
Adjustable VID Code Voltage
Accuracy
VFB_PWM_ADJ
−1.5
+1.5
%
Output voltage setting via VID
resistor
