DocID026928 Rev 1

7/16

RT2902

Electrical characteristics

VOL

Low level output voltage (RL = 10 kΩ)5

Low level output voltage (RL = 10 kΩ),

Tmin ≤ Tamb ≤ Tmax

Slew rate

(VCC+ = 15 V, Vin = 0.5 to 3 V, RL = 2 kΩ,

CL = 100 pF, unity gain)

0.4

V/µs

GBP

Gain bandwidth product

(VCC+ = 30 V, Vin = 10 mV, RL = 2 kΩ, CL = 100 pF)

1.3

MHz

THD

Total harmonic distortion

(f = 1 kHz, AV = 20 dB, RL = 2 kΩ, Vo = 2 Vpp,

CL = 100 pF, VCC+ = 30 V)

0.015

Equivalent input noise voltage

(f = 1 kHz, RS = 100 Ω, VCC+ = 30 V)

VO1/VO2

Channel separation(3)

(1 kHz

≤ f ≤ 20 kHz)

120

VO = 1.4 V, RS = 0 Ω, 5 V < VCC+ < 30 V, 0 V < Vic < (VCC+) - 1.5 V.

2. The direction of the input current is out of the IC. This current is essentially constant, independent of the

state of the output, so there is no change in the loading charge on the input lines.

3. Due to the proximity of external components ensure stray capacitance does not cause coupling between

these external parts. This typically can be detected as this type of capacitance increases at higher

frequencies.

Table 3. VCC+ = 5 V, VCC- = ground, Vo = 1.4 V, Tamb = 25 °C

(unless otherwise specified) (continued)

Symbol

Parameter

Min.

Typ.

Max.

Unit

------------
