This is information on a product in full production.

November 2012

Doc ID 023077 Rev 10

1/74

1

STRFNFCA

Near field communication transceiver

Datasheet

−production data

Features

■

Operating modes supported:

– Reader/Writer

– Card Emulation

– Peer-to-Peer

■

Hardware features

– Dedicated internal frame controller

– Highly integrated Analog Front End (AFE)

for RF communications

– Transmission and reception modes

– Optimized power management

– Tag Detection mode

– Field Detection mode

■

RF communication @13.56 MHz

– ISO/IEC 14443 Type A and B in Reader

and Card Emulation modes

– ISO/IEC 15693 in Reader mode

– ISO/IEC 18092 in Reader and Card

Emulation modes

■

Communication interfaces with a Host

Controller

– Serial peripheral interface (SPI) Slave

interface up to 2 Mbps

– Universal asynchronous

receiver/transmitter (UART) up to 2 Mbps in

Reader mode only (not available for Card

Emulation mode)

– 256-byte command buffer (FIFO)

■

32-lead, 5x5 mm, very thin fine pitch quad flat

(VFQFPN) ECOPACK® package

Applications

Typical protocols supported:

■

ISO/IEC 14443-3 Type A and B tags

■

ISO/IEC 15693

■

ISO/IEC 18000-3M1 tags

■

NFC Forum tags: Types 1, 2, 3 and 4

■

ST Dual Interface EEPROM

Typical STRFNFCA applications include:

■

Handheld readers (OTP, PIN pad, POS)

– E-payment, physical access control,

transport, and government

■

PC-Link (USB /Serial/PCMCIA)

– E-payment, security access &

authentication, data exchange)

■

USB token

– Security access & authentication, data

exchange

■

Integrated solution (chipset)

■

Keyboard, laptop, set top box, printer, TV, etc.

■

E-payment, data exchange, Bluetooth pairing,

security access

VFQFPN32 5x5 mm

www.st.com
