5 / 15 page ![]() CAT6243 www.onsemi.com 5 Table 5. ELECTRICAL CHARACTERISTICS (VIN = (VOUT + 1 V) or VIN_MIN, whichever is higher, CIN = 1 mF, COUT = 2.2 mF, for typical values TA = 25°C, for Bold values TA = −40°C to 85°C; unless otherwise noted.) Symbol Unit Max Typ Min Conditions Parameter ENABLE INPUT VHI Logic High Level VIN = 1.8 to 5.5 V 1.6 V VLO Logic Low Level VIN = 1.8 to 5.5 V 0.4 V IEN Enable Input Current VEN = 0.4 V 0.15 1 mA VEN = VIN = 2.5 V 1 3 REN Enable pull−down resistor 2.5 M W TIMING TON Turn−On Time CBYP = 0 pF 230 ms CBYP = 470 pF 1600 THERMAL PROTECTION TSD Thermal Shutdown 145 °C THYS Thermal Hysteresis 10 °C 7. Performance guaranteed over the indicated operating temperature range by design and/or characterization tested at TJ = TA = 25_C. Low duty cycle pulse techniques are used during testing to maintain the junction temperature as close to ambient as possible. |
|
|
