ADA4807-1/ADA4807-2/ADA4807-4

Data Sheet

Rev. B | Page 18 of 33

SLEW, TRANSIENT, SETTLING TIME, AND CROSSTALK

100

120

140

160

180

200

220

240

260

280

–40

–25

–10

110

125

TEMPERATURE (°C)

RISING EDGE

FALLING EDGE

G = +1

RLOAD = 1kΩ

VS = ±5V

VOUT = 5V p-p

VS = ±2.5V

VOUT = 2V p-p

Figure 36. Slew Rate vs. Temperature

–15

–10

–5

0.1

0.2

0.3

0.4

0.5

0.6

0.7

TIME (µs)

G = +1

RLOAD = 1kΩ

VS RANGE = ±1.5V TO ±5V

Figure 37. Small Signal Transient Response for Various Supplies

–1.5

–1.0

–0.5

0.5

1.0

1.5

100

200

300

400

500

600

700

800

900

TIME (ns)

G = +1

RLOAD = 1kΩ

±1.5V

±2.5V

±5V

Figure 38. Large Signal Transient Response for Various Supplies

–0.5

–0.4

–0.3

–0.2

–0.1

0.1

0.2

0.3

0.4

0.5

TIME (ns)

VS = ±5V

OUTPUT STEP = 5V p-p

VS = ±2.5V

OUTPUT STEP = 2V p-p

Figure 39. Settling Time to 0.1%
