ADA4807-2ARMZ-R7 Datasheet(PDF) 19 Page - Analog Devices

Part # ADA4807-2ARMZ-R7
Description  3.1 nV/?숰z, 1 mA, 180 MHz, Rail-to-Rail Input/Output Amplifiers
PDF  33 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  AD [Analog Devices]
Direct Link  http://www.analog.com
Logo AD - Analog Devices

ADA4807-2ARMZ-R7 Datasheet(HTML) 19 Page - Analog Devices

Back Button ADA4807-2ARMZ-R7 Datasheet HTML 15Page - Analog Devices ADA4807-2ARMZ-R7 Datasheet HTML 16Page - Analog Devices ADA4807-2ARMZ-R7 Datasheet HTML 17Page - Analog Devices ADA4807-2ARMZ-R7 Datasheet HTML 18Page - Analog Devices ADA4807-2ARMZ-R7 Datasheet HTML 19Page - Analog Devices ADA4807-2ARMZ-R7 Datasheet HTML 20Page - Analog Devices ADA4807-2ARMZ-R7 Datasheet HTML 21Page - Analog Devices ADA4807-2ARMZ-R7 Datasheet HTML 22Page - Analog Devices ADA4807-2ARMZ-R7 Datasheet HTML 23Page - Analog Devices Next Button
Zoom Inzoom in Zoom Outzoom out
 19 / 33 page
background image
Data Sheet
ADA4807-1/ADA4807-2/ADA4807-4
Rev. B | Page 19 of 33
–15
–10
–5
0
5
10
15
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0pF
5pF
10pF
15pF
TIME (µs)
VS = ±2.5V
G = +1
Figure 40. Small Signal Transient Response for Various Capacitive Loads
–160
–140
–120
–100
–80
–60
–40
–20
0
0.0001
0.001
0.01
0.1
1
10
100
1000
FREQUENCY (MHz)
VS = ±2.5V
VOUT = 2V p-p
DISABLE = 2.5V
DRIVING AMP 1
DRIVING AMP 2
Figure 41. ADA4807-2 Crosstalk vs. Frequency
–140
–120
–100
–80
–60
–40
–20
0
100
1k
10k
100k
1M
10M
100M
1G
FREQUENCY (Hz)
VS = ±2.5V
VOUT2, VOUT3, VOUT4 = 1V p-p
G = +1
RLOAD = 1kΩ
VOUT1
Figure 42. ADA4807-4 All Hostile Crosstalk
