6 / 15 page

Note 1: NA100 - denotes a bin kit comprising of all flux bins with a minimum flux of 1,590 lumens and chromaticity bins at the 6500K color point.

Note 2: For ordering information on all available bin kits, please see PDS-001788: SBT-90 Binning & Labeling document.

PDS-001540 Rev 15

Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com

175 New Boston Street • Woburn, MA 01801

Ordering Part Number1,2

Color

Description

SBT-90-W57S-F71-NA100

5700K White

White SBT-90 consisting of a 9mm2 LED on ceramic substrate

SBT-90-W65S-F71-NA100

6500K White

SBR-90-W57S-R71-NA100

5700K White

SBR-90 evaluation module consisting of a SBT-90 surface mount device mounted on

an aluminum star board

SBR-90-W65S-R71-NA100

6500K White

Ordering Part Number2

Color

Description

SBT-90-R-F75-HN100

Red

Red SBT-90 consisting of a 9 mm2 LED on a ceramic substrate

SBR-90-R-R75-HN100

Red

SBR-90 evaluation module consisting of a SBT-90 surface mount device mounted

on an aluminum star board

Ordering Information

SBT-90 Product Datasheet
