SBR-90-R-R75-HN100 datasheet(1/15 Pages) LUMINUS

Part #	SBR-90-R-R75-HN100

Description	Extremely high optical output from a 9 mm2 square emitter:

PDF	15 Pages

Scroll/Zoom	100%

Manufacturer	LUMINUS [Luminus, Inc]

Direct Link	https://www.luminus.com/

Logo

1 / 15 page

Applications

• Fiber-coupled illumination

• Architectural and Entertainment

lighting

• Projection and micro-display based

applications

• High-Brightness and large format

LCD back-light units

• Edge-illuminated lighting guides

• High output, Etendue-limited

lighting applications

Features:

• Extremely high optical output from a 9 mm2 square emitter:

• Up to 2300 lumens at 13.5A from a single chip (White)

• Over 1,600 lumens at 13.5A (Red)

• Choice of 5700K or 6500K color point

• High thermal conductivity package - junction to case thermal resistance of only

0.5 °C/W

• Large, monolithic chip with uniform emitting area of 9 mm2

• Unencapsulated die with low profile protective window optimizes optical coupling in

etendue-limited applications

• Electrically isolated thermal path

• Environmentally friendly: RoHS compliant

Table of Contents

Technology Overview ......2

Binning Structure ..........3

Chromaticity Bins ..........4

Product Shipping &

Labeling Information.......5

Ordering Information ......6

Electrical Characteristics ...7

Optical Characteristics .....8

White Characteristics.......9

Radiation Patterns ....... 10

Output vs Temp ,Lifetime and

Spectrum................ 11

Mechanical Dimensions .. 12

Solder Profile ............ 14

History of Changes . . . . . . . 15

1

PDS-001540 Rev 15

Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com

175 New Boston Street • Woburn, MA 01801

SBT-90 LEDs

SBT-90 Product Datasheet

Similar Part No. - SBR-90-R-R75-HN100
