Data Sheet

ADPA7008

OUTLINE DIMENSIONS

registered trademarks are the property of their respective owners.

One Analog Way, Wilmington, MA 01887-2356, U.S.A.

Rev. 0 | 28 of 28

Figure 85. 18-Terminal Ceramic Leadless Chip Carrier with Heat Sink [LCC_HC]

(EH-18-1)

Dimensions shown in millimeters

ORDERING GUIDE

Model1, 2

Temperature Range

Package Description

Package Option

ADPA7008AEHZ

−40°C to +85°C

18-Terminal Ceramic Leadless Chip Carrier with Heat Sink [LCC_HS]

EH-18-1

ADPA7008AEHZ-R7

−40°C to +85°C

18-Terminal Ceramic Leadless Chip Carrier with Heat Sink [LCC_HS]

EH-18-1

1 Z = RoHS Compliant Part.

2 For the ADPA7008AEHZ and the ADPA7008AEHZ-R7, the MSL Rating is MSL3.

EVALUATION BOARDS

Model1

Description

ADPA7008-EVALZ

Evaluation Board

1 Z = RoHS Compliant Part.
