STM32U545NET3QTR datasheet(169/283 Pages) STMICROELECTRONICS

169 / 283 page

Table 65. SRAM static power consumption in Stop 3 when supplied by SMPS

Symbol

Parameter

Typ

Max(1)

Unit

25°C

55°C

85°C 105°C 125°C 25°C

55°C

85°C 105°C 125°C

IDD(SRAM1_64kB)(2)

SRAM1 64-Kbyte page x static consumption

(SRAM1PDSx = 1 versus SRAM1PDSx = 0)

0.2

0.6

2.1

5.1

11.5

0.5

1.7

6.3

16.0

35.0

µA

IDD(SRAM2_8KB)(3)

SRAM2 8-Kbyte page 1 static consumption

(SRAM2PDS1 = 1 versus SRAM2PDS1 = 0)

0.1

0.2

0.8

1.8

4.0

0.2

0.7

2.4

5.4

12.0

IDD(SRAM2_56KB)(3)

SRAM2 56-Kbyte page 2 static consumption

(SRAM2PDS2 = 1 versus SRAM2PDS2 = 0)

0.2

0.7

2.6

6.1

13.6

0.6

2.1

7.8

19.0

41.0

IDD(SRAM4)

SRAM4 static consumption

(SRAM4PDS = 1 versus SRAM4PDS = 0)

0.0

0.1

0.5

1.3

2.9

0.1

0.4

1.5

3.9

8.8

IDD(ICRAM)

ICACHE SRAM static consumption

(ICRAMPDS = 1 versus ICRAMPDS = 0)

0.0

0.1

0.4

0.9

1.9

0.1

0.3

1.2

2.8

5.8

IDD(DC1RAM)

DCACHE1 SRAM static consumption

(DC1RAMPDS = 1 versus DC1RAMPDS = 0)

0.0

0.2

0.5

1.0

0.1

0.2

0.6

1.5

3.0

IDD(PRAM)

FMAC, FDCAN and USB SRAM static consumption

(PRAMPDS = 1 versus PRAMPDS = 0)

0.0

0.1

0.3

0.6

0.0

0.1

0.3

0.9

1.9

IDD(PKARAM)

PKA SRAM static consumption

(PKARAMPDS = 1 versus PKARAMPDS = 0)

0.0

0.2

0.5

1.1

0.1

0.2

0.6

1.5

3.4

1. Evaluated by characterization. Not tested in production.

2. SRAM1 total consumption is 3 × IDD(SRAM1_64KB).

3. SRAM2 total consumption is IDD(SRAM2_8KB) + IDD(SRAM2_56KB).
