ABSOLUTE MAXIMUM RATINGS

TA = 25°C unless otherwise specified.

Table 2. Absolute Maximum Ratings

PARAMETER

RATING

Supply Voltage (VS)

6V

Input Voltage

GND to VS

Differential Input Voltage1

±6V

Input Current (Indefinite)

±10mA

Input Current (Duration < 1sec)

±100mA

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60sec)

300°C

1

For supplies less than 6V, the differential input voltage is equal to ±VS.

Stresses at or above those listed under Absolute Maximum Ratings may cause permanent damage to the product.

This is a stress rating only; functional operation of the product at these or any other conditions above those indicated

in the operational section of this specification is not implied. Operation beyond the maximum operating conditions

for extended periods may affect product reliability.

Thermal Resistance

Thermal performance is directly linked to PCB design and operating environment. Careful attention to PCB thermal

design is required. θJA is specified for the worst-case conditions, that is, a device soldered in a circuit board for

surface-mount packages and measured using a standard 4-layer board, unless otherwise specified. θJC is the

junction-to-case thermal resistance.

Table 3. Thermal Resistance

PACKAGE TYPE

θJA

θJC

UNIT

8-Lead MSOP (RM)

142

45

°C/W

ESD Caution

ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can

discharge without detection. Although this product features patented or proprietary

protection circuitry, damage may occur on devices subjected to high energy ESD. Therefore,

proper ESD precautions should be taken to avoid performance degradation or loss of

functionality.
