Data Sheet
MAX74822
analog.com
Rev. 0
11 of 16
THEORY OF OPERATION
Lower Supply Current for 1MHz Gain Bandwidth
The MAX74822 typically uses 45µA of current per amplifier, which is much less than the 200µA to 700µA used in
earlier generation parts with similar performance. This makes the MAX74822 a good choice for upgrading portable
designs for longer battery life. Alternatively, additional functions and performance can be added at the same
current drain.
Higher Output Current
At 5V single supply, the short-circuit current is typically 60mA. Even 1V from the supply rail, the MAX74822 amplifier
can provide a 30mA output current, sourcing, or sinking.
