STV2000
10/38
VIDEO PRE-AMP SECTION
HORIZO NTAL BREATHING COMPENSATIO N
HBRdc
Breathing input DC Control Range
1
10.5
V
HSC
Horizontal size compensation, EW DC
voltage variation under full range of
HBRdc
0.4
V
Symbol
Parameter
Test Conditi ons
Min
Typ
Max
Unit
DC Electrical Characteristics (VAVCC =PVCC = 10.5V, Tamb = 25
oC)
VAVcc
Video Section Analog Supply Voltage
9.5
10.5
11.5
V
PVcc
Power Section Supply Voltage
9.5
10.5
11.5
V
IS
Supply Current of VAVcc & PVcc
60
mA
VIN
Video Input Voltage Amplitude
0.7
1
Vpp
VOUT
Typical Output Voltage Range
0.5
7
V
VDC
Output DC level (Black level)
1.5
V
AC Electrical Characteristics (VAVCC =PVCC = 10.5V, CL = 12pF, RL = 1KΩ, Tamb = 25
oC)
Symbol
Parameter
Condition
Min
Typ
Max
Unit
AV
Maximum Gain
Max Contrast and Drive
I2C Gainwin = 1
18
dB
CAR
Contrast Attenuation Range
VIN = 0.7Vpp
Contrast and Drive at
POR
30
dB
DAR
Drive Attenuation Range
30
dB
GM
Gain Match
VIN = 0.7Vpp,
VOUT = 4Vpp, Contrast
and Drive= 0.87Max
+-0.1
dB
BW
Large Signal Bandwidth
VIN=0.7Vpp,
VOUT = 4Vpp, Contrast
and Drive = 0.87Max
At -3dB
70
MHz
DIS
Video Output Distortion
f=1MHz, VIN=1Vpp,
VOUT = 1Vpp
0.3
%
tR,tF
Video Output Rise and Fall Time
VIN = 0.7Vpp,
VOUT =4Vpp,Contrast
and Drive=0.87Max
5ns
dVo
Overshoot of output with respect to
actual output amplitude
CLOAD=5pF
5
7
%
BRT
Brightness max DC level
Brightness min DC level
2.5
0
V
V
RL
Equivalent Load on Video Output
Tj<TjMAX
1k
Ω
Tsample
Hold time
100
ms
Symbol
Parameter
Test Conditi ons
Min
Typ
Max
Unit
4
