STV2000
27/38
OPERATING DESCRIPTION (continued)
Figure 18. Waveforms VOUT, BRT, CONT
Figure 19. Waveforms (DRIVE adjustment)
HSYNC
V
CONT
(4)
BPCP
BLK
Video IN
V
BRT
(3)
V
BLACK
(2)
V
DC
(1)
CONT
BRT
0.4V fixed
V
OUT1,VOUT2,VOUT3
Note : 1. VDC = 1.5V
2. VBLACK =VDC + 0.4V
3. VBRT =VBLACK + BRT (with BRT = 0 to 2.5V)
4. VCONT =VBRT + CONT with CONT = k x video (CONT = 5VPP max. for VIN = 0.7VPP)
HSYNC
V
CONT
BPCP
BLK
Video IN
V
BRT
V
BLACK
VDC
V
OUT1
V
OUT2
,
V
OUT3
.
,
two examples of
drive adjustment (1)
Note :
1. Drive adjustment modifies the following voltages : VCONT,VBRT.
Drive adjustment does not modify the following voltages : VDC and VBLACK.
6
