background image
STV2001
7/46
4 - ABSOLUTE MAXIMUM RATINGS
5 - THERMAL DATA
6 - SYNC INPUT
Symbol
Parameter
Value
Unit
SAVcc
Scanning Section Analog Supply Voltage
13.5
V
VAVcc
Video Section Analog Supply Voltage
13.5
V
PVcc
Supply Voltage for Video Pre-Amp Section
13.5
V
Vdd
Logic Section Supply Voltage
5.5
V
VESD
ESD susceptibility HBM model 100pF & 1.5k
Ω
EIAJ Norm 200pF & 0
Ω
2
300
kV
V
Tstg
Storage Temperature
-40 to 150
oC
Tj
Junction Temperature
150
oC
Toper
Operating Temperature (Device ambient)
0 to 70
oC
Symbol
Parameter
Value
Unit
RTH(j-a)
Junction to Ambient Thermal Resistance (MAX)
46
oC/W
Operating Conditions (VDD = 5V, Tamb = 25°C)
Symbol
Parameter
Test Conditions
Min
Typ
Max
Unit
HSVR
Voltage on Hin
0
5
V
MinD
Min Hin pulse duration
0.7
us
Mduty
Max Hin Duty Cycle
25
%
VSVR
Voltage on Vin
0
5
V
VSW
Min Vin pulse duration
5
us
VSD
Max Vin Duty Cycle
15
%
Electrical Characteristics (VDD = 5V, Tamb = 25°C)
VINTH
Horizontal & Vertical Input Logic Level
Low Level
High Level
2.2
0.8
V
V
RIN
Horizontal & Vertical Pull-Up Resistor
200
k
Ω
