STV2001
19/46
13 - TYPICAL OUTPUT WAVEFORMS
Function
Sub
Address
Pin
Byte
Specification
Effect on Screen
Vertical Size
1000 0000
1111 1111
Vertical
Position
x000 0000
x100 0000
x111 1111
VOUTDC = 3.2 V
VOUTDC = 3.5 V
VOUTDC = 3.8 V
Vertical
S
Linearity
0000 0000
Inhibited
1111 1111
EW Corner
Top
(Symmetri-
cal)
Keystone,
EW Inhibited
1000 0000
1111 1111
2.25V
3.75V
Vpp
∆V
1.25Vpp
2V
1.25Vpp
2V
