APTM120U10SCAVG

www.microsemi.com

1 – 8

D

DK

S

SK

G

G, SK and DK terminals are for control signals only

(not for power)

D

S

DK

SK

SK

G

These Devices are sensitive to Electrostatic Discharge. Proper Handling Procedures Should Be Followed. See application note

APT0502 on www.microsemi.com

Application

•

Welding converters

•

Switched Mode Power Supplies

•

Uninterruptible Power Supplies

•

Motor control

Features

•

Power MOS 7

-

-

Low input and Miller capacitance

-

Low gate charge

-

Avalanche energy rated

-

Very rugged

•

SiC Parallel Schottky Diode

-

Zero reverse recovery

-

Zero forward recovery

-

Temperature Independent switching behavior

-

Positive temperature coefficient on VF

•

Kelvin source for easy drive

•

Kelvin drain for voltage monitoring

•

Very low stray inductance

-

Symmetrical design

-

M5 power connectors

-

M3 power connectors

•

High level of integration

•

AlN substrate for improved MOSFET thermal

performance

Benefits

•

Outstanding

performance

at

high

frequency

operation

•

Direct mounting to heatsink (isolated package)

•

Low junction to case thermal resistance

•

Low profile

•

RoHS Compliant

Single switch

Series & SiC parallel diodes

MOSFET Power Module
