background image
Command codes
M24LR04E-R
102/142
Doc ID 022208 Rev 5
Request parameter:
●
Request flags
●
UID (optional)
●
Password number (01h = Pswd1, 02h = Pswd2, 03h = Pswd3, other = Error)
●
Data
Response parameter:
●
no parameter.
Response parameter:
●
Error code as Error_flag is set:
–
10h: the password number is incorrect
–
12h: the session was not opened before the password update
–
13h: the specified block was not successfully programmed
–
0Fh: the presented password is incorrect
.
Table 77.
Write-sector Password response format when Error_flag is NOT set
Response
SOF
Response_flags
CRC16
Response
EOF
8 bits
16 bits
Table 78.
Write-sector Password response format when Error_flag is set
Response
SOF
Response_
flags
Error code
CRC16
Response
EOF
8 bits
8 bits
16 bits
Figure 67.
Write-sector Password frame exchange between VCD and M24LR04E-R
VCD
SOF
Write-
sector
Password
request
EOF
M24LR04E-R
<-t1-> SOF
Write-sector
Password
response
EOF
Write sequence
when error
M24LR04E-R
<---------------- Wt -------------> SOF
Write-
sector
Password
response
EOF
