M24LR04E-R
Command codes
Doc ID 022208 Rev 5
99/142
.
When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that
starts the Get System Info command to the end of the M24LR04E-R response.
When configured in the RF write in progress mode, the RF WIP/BUSY pin remains in high-Z
state.
Figure 65.
Get System Info frame exchange between VCD and M24LR04E-R
VCD
SOF
Get System Info
request
EOF
M24LR04E-R
<-t1-> SOF
Get System Info
response
EOF
