System memory area

M24LR04E-R

26/142

Doc ID 022208 Rev 5

4.2

M24LR04E-R block security in I²C mode (I2C_Write_Lock bit

area)

In the I2C mode only, it is possible to protect individual sectors against Write operations.

This feature is controlled by the I2C_Write_Lock bits stored in the 2 bytes of the

I2C_Write_Lock bit area. I2C_Write_Lock bit area starts from location 2048 (see Table 13).

To access the I2C_Write_Lock bit area, the device select code used for any I2C command

must have the E2 Chip Enable address at 1.

Using these 16 bits, it is possible to write-protect all the 4 sectors of the M24LR04E-R

memory. Each bit controls the I2C write access to a specific sector as shown in Table 13. It

is always possible to unprotect a sector in the I2C mode. When an I2C_Write_Lock bit is

reset to 0, the corresponding sector is unprotected. When the bit is set to 1, the

corresponding sector is write-protected.

In I2C mode, read access to the I2C_Write_Lock bit area is always allowed. Write access

depends on the correct presentation of the I2C password.

On delivery, the default value of the two bytes of the I2C_Write_Lock bit area is reset to 00h.

4.3

Configuration byte and Control register

The M24LR04E-R offers an 8-bit non-volatile Configuration byte located at I²C location 2320

of the system area used to store the RF WIP/BUSY pin and the energy harvesting

configuration (see Table 14).

The M24LR04E-R also offers an 8-bit volatile Control register located at I²C location 2336 of

the system area used to store the energy harvesting enable bit as well as a FIELD_ON bit

indicator (see Table 15).

4.3.1

RF WIP/BUSY pin configuration

The M24LR04E-R features a configurable open drain output RF WIP/BUSY pin used to

provide RF activity information to an external device.

The RF WIP/BUSY pin functionality depends on the value of bit 3 of the Configuration byte.

●

RF busy mode

When bit 3 of the Configuration byte is set to 0, the RF WIP/BUSY pin is configured in RF

busy mode.

The purpose of this mode is to indicate to the I²C bus master whether the M24LR04E-R is

busy in RF mode or not.

In this mode, the RF WIP/BUSY pin is tied to 0 from the RF command Start Of Frame (SOF)

until the end of the command execution.

If a bad RF command is received, the RF WIP/BUSY pin is tied to 0 from the RF command

SOF until the reception of the RF command CRC. Otherwise, the RF WIP/BUSY pin is in

high-Z state.

Table 13.

I2C_Write_Lock bit

I2C byte address

Bits [4:15]

Bits [3:0]

E2 = 1

2048

Don’t care

sectors 0-3
