SSL21083AT

All information provided in this document is subject to legal disclaimers.

© NXP B.V. 2013. All rights reserved.

Product data sheet

Rev. 6 — 4 October 2013

13 of 22

NXP Semiconductors

SSL21083AT

Compact non-dimmable LED driver IC

9.

Limiting values

[1]

[2]

An internal clamp sets the supply voltage.

[3]

Human body model: equivalent to discharging a 100 pF capacitor through a 1.5 k

 series resistor.

[4]

Charged device model: equivalent to charging the IC up to 1 kV and the subsequent discharging of each

pin down to 0 V over a 1

 resistor.

10. Thermal characteristics

Table 5.

Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134).

Symbol

Parameter

Conditions

Min

Max

Unit

General

SR

slew rate

on pin DRAIN

5

+5

V/ns

total power dissipation

SO8 package

-

0.6

W

ambient temperature

40

+125

C

junction temperature

40

+150

C

storage temperature

55

+150

C

Voltages

supply voltage

continuous

[1]

0.4

+20

V

voltage on pin DRAIN

0.4

+600

V

voltage on pin HV

current limited

0.4

+600

V

voltage on pin SOURCE

current limited

0.4

+5.2

V

voltage on pin NTC

current limited

0.4

+5.2

V

Currents

supply current

at pin VCC

[2] -

20

mA

current on pin DRAIN

1

+1

A

current on pin SOURCE

1

+1

A

current on pin DVDT

duration 20

s

maximum

-

1.3

A

electrostatic discharge

voltage

human body model;

pins DRAIN and HV

[3]

1

+1

kV

human body model;

all other pins

2

+2

kV

charged device

[4]

500

+500

V

Table 6.

Thermal characteristics

Symbol Parameter

Conditions

Typ

Unit

thermal resistance from junction to ambient

in free air; SO8 package, PCB: 2 cm

3 cm,

2-layer, 35

m Cu per layer

142

K/W

in free air; SO8 package; PCB: JEDEC 2s2p

72

K/W



j-top

thermal characterization parameter from

junction to top of package

top package temperature measured at the

warmest point on top of the case; SO8 package

3.4

K/W
