SSL21083AT

All information provided in this document is subject to legal disclaimers.

© NXP B.V. 2013. All rights reserved.

Product data sheet

Rev. 6 — 4 October 2013

3 of 22

NXP Semiconductors

SSL21083AT

Compact non-dimmable LED driver IC

4.

Quick reference data

[1]

An internal clamp sets the supply voltage. The current into the VCC pin must not exceed the maximum IDD

value (see Table 5).

5.

Ordering information

5.1 Ordering options

Remark: All voltages are in V (AC) unless otherwise specified.

Table 1.

Quick reference data

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

supply voltage

operating range

[1] 8

-

16

V

drain-source on-state

resistance

4

5

6



6

7.5

9



conversion frequency

-

100

-

kHz

current on pin DRAIN

2

-

+2

A

voltage on pin DRAIN

0.4

-

+600

V

Table 2.

Ordering information

Type number

Package

Name

Description

Version

SSL21083AT

SO8

plastic small package outline body; 8 leads; body width

3.9 mm

SOT96-1

Table 3.

Ordering options

Type

Input voltage

Internal MOSFET

characteristics

Package

SSL21083AT

100 V; 120 V; 230 V

600 V (DC); 5



SO8
