21 / 100 page  CC1100 SWRS038D Page 21 of 92 Component Value at 315MHz Value at 433MHz Value at 868/915MHz Manufacturer C51 100 nF ± 10%, 0402 X5R Murata GRM1555C series C81 27 pF ± 5%, 0402 NP0 Murata GRM1555C series C101 27 pF ± 5%, 0402 NP0 Murata GRM1555C series C121 6.8 pF ± 0.5 pF, 0402 NP0 3.9 pF ± 0.25 pF, 0402 NP0 1.0 pF ± 0.25 pF, 0402 NP0 Murata GRM1555C series C122 12 pF ± 5%, 0402 NP0 8.2 pF ± 0.5 pF, 0402 NP0 1.5 pF ± 0.25 pF, 0402 NP0 Murata GRM1555C series C123 6.8 pF ± 0.5 pF, 0402 NP0 5.6 pF ± 0.5 pF, 0402 NP0 3.3 pF ± 0.25 pF, 0402 NP0 Murata GRM1555C series C124 220 pF ± 5%, 0402 NP0 220 pF ± 5%, 0402 NP0 100 pF ± 5%, 0402 NP0 Murata GRM1555C series C125 220 pF ± 5%, 0402 NP0 220 pF ± 5%, 0402 NP0 100 pF ± 5%, 0402 NP0 Murata GRM1555C series C131 6.8 pF ± 0.5 pF, 0402 NP0 3.9 pF ± 0.25 pF, 0402 NP0 1.5 pF ± 0.25 pF, 0402 NP0 Murata GRM1555C series L121 33 nH ± 5%, 0402 monolithic 27 nH ± 5%, 0402 monolithic 12 nH ± 5%, 0402 monolithic Murata LQG15HS series L122 18 nH ± 5%, 0402 monolithic 22 nH ± 5%, 0402 monolithic 18 nH ± 5%, 0402 monolithic Murata LQG15HS series L123 33 nH ± 5%, 0402 monolithic 27 nH ± 5%, 0402 monolithic 12 nH ± 5%, 0402 monolithic Murata LQG15HS series L124 12 nH ± 5%, 0402 monolithic Murata LQG15HS series L131 33 nH ± 5%, 0402 monolithic 27 nH ± 5%, 0402 monolithic 12 nH ± 5%, 0402 monolithic Murata LQG15HS series L132 18 nH ± 5%, 0402 monolithic Murata LQG15HS series R171 56 kΩ ± 1%, 0402 Koa RK73 series XTAL 26.0 MHz surface mount crystal NDK, AT-41CD2 Table 15: Bill Of Materials for the Application Circuit The Gerber files for the CC1100EM reference designs ([5] and [6]) are available from the TI website. |
|
