241 / 283 page ![]() DS14216 Rev 1 241/283 STM32U545xx Electrical characteristics 258 5.3.28 ADF/MDF characteristics Unless otherwise specified, the parameters given in the table below are derived from tests performed under the ambient temperature, fAHB frequency and VDD supply voltage conditions summarized in Table 33, with the following configuration: • Output speed set to OSPEEDRy[1:0] = 10 • Capacitive load CL = 30 pF • Measurement points done at 0.5 × VDD level • I/O compensation cell activated • HSLV activated when VDD ≤ 2.7 V • Voltage scaling range 1 Refer to Section 5.3.14: I/O port characteristics for more details on the input/output alternate function characteristics. Table 118. ADF characteristics(1) Symbol Parameter Conditions Min Typ Max Unit fCCKI Input clock frequency via ADF_CCK[1:0] pin, in SLAVE SPI mode 1.71 ≤ VDD ≤ 3.6 V -- 25 MHz fCCKO Output clock frequency in MASTER SPI mode -- 25 fCCKOLF Output clock frequency in LF_MASTER SPI mode -- 5 fSYMB Input symbol rate in Manchester mode -- 20 tHCCKI tLCCKI ADF_CCK[1:0] input clock high and low time In SLAVE SPI mode 2 × Tadf_proc_ck(2) -- ns tHCCKO tLCCKO ADF_CCK[1:0] output clock high and low time In MASTER SPI mode 2 × Tadf_proc_ck -- tHCCKOLF tLCCKOLF ADF_CCK[1:0] output clock high and low time In LF_MASTER SPI mode Tadf_proc_ck - - tSUCCKI Data setup time with respect to ADF_CCK[1:0] input In SLAVE SPI mode: ADF_CCK[1:0] configured in input, measured on rising and falling edge 4.5 - - tHDCCKI Data hold time with respect to ADF_CCK[1:0] input 1- - tSUCCKO Data setup time with respect to ADF_CCK[1:0] output In MASTER SPI mode: ADF_CCK[1:0] configured in output, measured on rising and falling edge 5.5 - - tHDCCKO Data hold time with respect to ADF_CCK[1:0] output 0- - tSUCCKOLF Data setup time with respect to ADF_CCK[1:0] output In LF_MASTER SPI mode: ADF_CCK[1:0] configured in output, measured on rising and falling edge 19.5 - - ns tHDCCKOLF Data hold time with respect to ADF_CCK[1:0] output 0- - 1. Evaluated by characterization. Not tested in production. 2. Tadf_proc_ck is the period of the ADF processing clock. |
|
