STG3159
Pin connections and functions
3/18
1
Pin connections and functions
Figure 1.
Pin connections (top through view)
Figure 2.
Input equivalent circuit
Table 1.
Truth table
Sel
Switch S1
Switch S2
HON
OFF (1)
LOFF (1)
1.
High impedance
ON
Table 2.
Pin descriptions
Pin Nº
Symbol
Name and function
6, 4
S1, S2
Independent channels
3
D
Common channels
1
SEL
Control
2VCC
Positive supply voltage
5
GND
Ground (0V)
1
2
3
6
5
4
SEL
VCC
D
S2
GND
S1
DFN6L
S1
GND
S2
SEL
VCC
D
1
2
34
5
6
