TDA7480
10W MONO CLASS-D AMPLIFIER
10W OUTPUT POWER:
RL = 8
Ω/4Ω; THD = 10%
HIGH EFFICIENCY
NO HEATSINK
SPLIT SUPPLY
OVERVOLTAGE PROTECTION
ST-BY AND MUTE FEATURES
SHORT CIRCUIT PROTECTION
THERMAL OVERLOAD PROTECTION
DESCRIPTION
The TDA7480 is an audio class-D amplifier as-
sembled in Power DIP package specially de-
signed for high efficiency applications mainly for
TV and Home Stereo sets.
September 1998
®
L1 60
µH
8
Ω
+
-
+
-
PWM
PRE
11
8
C2 0.33
µF
IN1
C4 4.7nF
FEEDCAP
OUT
BOOT
C11
100nF
C12
560pF
R5
150
Ω
C14
470nF
6
4
VREG
C15
100nF
R4 12K
Ω
15
5
C10
2200
µF
C9
100nF
SGN-GND
10
MUTE
ST-BY
12
16
14
+VCC
ST-BY/
MUTE
C1
2.2
µF
R3
30K
R2
7K
VCC SIGN
C7
2200
µF
IN1
D96AU536E
-VCC
(Pin 17)
C6
100nF
C3
1nF
R1
10K
+5V
VCC POW
7,13
N.C.
C5 100nF
BOOTDIODE
C8
270pF
9
1,2,3,18,19,20
17
-VCC
FREQ
-VCC
-VCC
RF
-VCC
Figure 1: Test and Application Circuit.
ORDERING NUMBER: TDA7480
PDIP20 (14+3+3)
1/10
