PPC8567ECVTAQJGA Datasheet(PDF) 113 Page - Freescale Semiconductor, Inc |
|
|
|||||||||||||||||||||||||||||
PPC8567ECVTAQJGA Datasheet(HTML) 113 Page - Freescale Semiconductor, Inc |
|
|
113 / 139 page  MPC8568E/MPC8567E PowerQUICC III Integrated Processor Hardware Specifications, Rev. 1 Freescale Semiconductor 113 Package and Pinout PCI_REQ[4:1] AG29, AJ27, AH29, AB17 I OVDD — PCI_REQ[0] AC17 I/O OVDD — PCI_CLK AM26 I OVDD 39 PCI_DEVSEL AK23 I/O OVDD 2 PCI_FRAME AE21 I/O OVDD 2 PCI_IDSEL AB19 I OVDD — DDR SDRAM Memory Interface MDQ[0:63] B22, C22, E20, A19, C23, A22, A20, C20, G22, E22, E16, F16, E23, F23, F17, H17, A18, A17, B16, C16, B19, C19, E17, A16, A13, A14, A12, C12, A15, B15, B13, C13, G12, G11, H8, F8, D13, F12, E9, F9, A7, B7, C5, E5, C8, E8, D6, A5, E6, G6, E1, F1, G7, E7, E2, D1, C4, A3, B1, C1, A4, B4, C2, D2 I/O GVDD — MECC[0:7] C11, E11, D9, A8, D12, A11, A9, C9 I/O GVDD — MDM[0:8] A21, E21, D18, B14, F11, A6, G5, A2, A10 O GVDD — MDQS[0:8] D21, G20, C17, D14, E10, C6, F4, C3, C10 I/O GVDD — MDQS[0:8] C21, G21, C18, D15, F10, C7, F5, D3, B10 I/O GVDD — MA[0:15] K7, H7, L7, J8, K8, L10, H9, K9, H10, G10, L6, K10, K11, H3, J11, J12 OGVDD — MBA[0:2] K4, H6, L13 O GVDD — MWE K3 O GVDD — MCAS L3 O GVDD — MRAS K6 O GVDD — MCKE[0:3] L14, G13, K12, J13 O GVDD 11 MCS[0:3] J5, H2, K5, K2, O GVDD — MCK[0:5] G15, F20, E4, F14, E19, G3 O GVDD — MCK[0:5] G14, F19, E3, F13, E18, G2 O GVDD — MODT[0:3] G4, J1, J4, K1 O GVDD — MDIC[0:1] G1, H1 I/O GVDD 36 Local Bus Controller Interface LAD[0:31] M26, C30, F31, L24, G26, D30, M25, L26, D29, G32, G28, K26, B32, M24, G29, L25, E29, J23, B30, A31, J24, K23, H25, H23, F26, C28, B29, E25, D26, G24, A29, E27, I/O BVDD — LDP[0:3] G30, J26, H28, E26 I/O BVDD — LA[27] F29 O BVDD 5,9 LA[28:31] H24, C32, F30, H26 O BVDD 5,7,9 Table 79. MPC8567E Pinout Listing (continued) Signal Package Pin Number Pin Type Power Supply Notes |
|
