4872A–CORD–08/05
U4091BM-R
20. Bus Timing
Figure 20-1. Bus Timing Diagram
22. Package Information
t
wSTA
PS
t
hSTA
t
L
t
r
SDA
SCL
t
hDAT
P
t
hSTA
t
f
t
H
t
sSTA
t
sSTOP
P = Stop, S = Start
t
hDAT
21. Ordering Information
Extended Type Number
Package
Remarks
U4091BM-RFNGY
SSO44
Tube
U4091BM-RFNG3Y
SSO44
Taped and reeled
T4091R-DDB
Die
Die on foil
technical drawings
according to DIN
specifications
Package SSO44
Dimensions in mm
0.25
0.10
0.3
0.8
18.05
17.80
16.8
2.35
9.15
8.65
7.50
7.30
10.50
10.20
0.25
44
23
1
22
